Precision Machining Capabilites

---

GENERAL SPECIFICATIONS
Table Size (Round):                        24.8”
Travel (X, Y, Z):                        32” X 29.3” X 19.7”
Travel (A, C):                            -120 to + 30° / 0 to 360°
Spindle Taper:                        CAT 40
Spindle Speed:                        20,000 RPM
Tool Change Time (T-T / C-C):                2.5 Sec / 5.0 Sec
Rapid Feed (A, C):                        2,000° /Min, 6,000° / Min
Max X - Axis Feed:                        1968” / Min
Max Y - Axis Feed:                        1968” / Min
Max Z - Axis Feed:                        984” / Min
A - Axis (Table Tilt):                        150°
C - Axis (Table Rotate):                    360°
Max Tool Size:                        5.91” X 11.8”
Max Tool Weight:                        22 lbs.

COOLANT SYSTEM

Coolant thru Spindle: 220 psi standard

TABLE

Table Work Area (W x L)  31.5" x 15.7"

TRAVEL

X Axis: 27.6"

Y Axis: 15.7"

Z Axis: 11.8"

Spindle

16000 RPM

Thru spindle Coolant

TABLE

Table Work Area (W x L): 44.1" x 23.6"

Table Load Capacity: 1000 lbs.

TRAVEL

X Axis: 40.2"

Y Axis: 23.6"

Z Axis: 23.6"

Full 4th Axis Rotary Table

Spindle

Cat 50

8000 RPM

COOLANT SYSTEM

Coolant thru Spindle: 220 psi standard

Max. spindle speed

10,000 rpm
Travels

X: 480mm Y: 360mm Z: 270mm

Tool storage capacity

14pcs.

Rapid traverse rate

(XYZ area)

36m/min×36m/min×50m/min

TABLE

Table Work Area (W x L): 27.5" x 17.7"

Table Load Capacity: 1000 lbs.

TRAVEL

X Travel 23.9"

Y Travel 17.7"

Z Travel 17.7"

4th Axis Rotary Table

Spindle

Cat 40

12000 RPM

 GA-2000 SERIES

 Chuck Size 8"

 Bar Capacity 2.0" ( 51 mm )

X Travel 12"

Y Travel 8"

Z Travel 8"

6000 Watt Fiber Laser Cutter

5'x10' Table size machined parts

7" x 7" Marking

2.75" x 2.75" Engraving

Mitutoyo B-231

50.5" x 43.38" Table size

Helmel Microgage

6 x 9 x 5 Table Size

Scale .1um

CNC Programming:

MasterCam 2025
